- Size: according to customer's request
- Place of Origin: Shandong,China
- Brand Name: shandong wintech machinery technology Co.,Ltd
- Model Number: WTSFD
- Weight: 1000.000 kg
- :
- :
- :
- :
- :
- :
- :
Product Function Brief of Reactor:
A. Operating principle: Break down or recombined the materials through mixing, filling and cooling, to promote the reaction of polymerization.
B. Components: Body, gears, mixing devices, heating devices, cooling devices, seal, etc.
C. Auxiliary Equipment: Distillation column, head tank, condenser, water separator, collecting cans, filters, etc..
D. Widely used in: Resins, adhesives, paint, cosmetics, pharmaceutical and other chemical production.
E. Applicable Field: All the liquid-liquid, liquid-powder reaction industry.
Application field: It is suitable for Petroleum, chemical, rubber, pesticide, dye, medicine, food, to complete the vulcanization, nitration, hydrogenation, alkylation, polymerization, condensation process of container
Pre-sales Service:
Customization:
We can specially customize products if you tell us any special requests,such as spare parts, cylindrical tank, material, output, pump...
After-sales Service:
1. One-year free warranty and life-long maintenance service
2. Equipment operation and maintenance vedio guide for the customers
3. Help to do worker training
4. On-line support every day
FAQ:
1.Q:Are you a factory or trading company?
A:We are one of the largest evaporator manufactory in China
2.Q:Can we visit your factory before placing orders?
A:Sure,warmly welcome to our factory!
3.Q:What's the info needed if I send one inquiry?
A:Pls tell us the working conditions,mediums,temperature,pressure, equipment's material,size,quantity,and other special requests
4.Q:What is the MOQ?
A:We accept loose quantity order,any trial orders or mixed order
5.Q:How does your factory do quality control?
A:Quality is priority,we make relevant strict testing before delivery
Our factory has already obtained ISO9001 quality and ISO 14001
Environmental management system certificate
- Size: according to customer's request
- Place of Origin: Shandong,China
- Brand Name: shandong wintech machinery technology Co.,Ltd
- Model Number: WTSFD
- Weight: 1000.000 kg
- :
- :
- :
- :
- :
- :
- :
Technical Parameters:
Composition | Instructions |
Specification (L) | 50-50000 |
Design Pressure (Mpa) | Atmospheric Pressure or under pressure |
Material | Carbon steel, stainless steel, enamel, graphite |
Heating Forms | Electrical heating with medium in jacket, external half coil steam heating, external half conduction oil heating, hot water infrared heating etc. |
Cooling Forms | Refrigeration medium in the internal pipe jacket |
Blending Power | Model selection is made according to material viscosity, liquid-solid ratio, liquid specific gravity, solid specific gravity, solid granularity, rotation speed, paddle type, with or without baffle or internal coil. |
Stirring blade Forms | Anchor type, frame type, flat paddle type, pitched paddle type, ribbon type, turbo type, pusher type and multiple compound type |
Seal | Mechanical seal or stuff packing seal |
Inner Surface Treatment | Polished or no polished |
Discharge Valve | Flanged ball valve, open downward discharge valve and others |
Technological Pipe Hole | Manhole, sight glass, distillation mouth, imported materials, pressure gauge port, temperature, mouth, mouth filling N2, |
