The vapor body is conservatively designed both in diameter and height. It is important to have an adequate free space above the liquor level to allow the liquor droplets entrained in the vapor leaving the boiling surface to reach equilibrium and return by gravity to the circulating slurry. The large diameters result in low vapor velocities which minimize entrainment. A mesh type entrainment separator is typically installed in the upper portion of the vapor body to reduce entrainment.

Heat exchangers can be located on the discharge or suction side of the circulating pump. In some cases, both discharge and suction side heat exchangers have been provided in the same circulating system to maximize heat transfer surface. Multiple circulating systems can be supplied for the same vapor body on large evaporators.
A wide variety of forced circulation evaporator designs are available, tailored for the particular application.

Features

Fouling of tubes is minimized
High Recirculation is to be maintained inside the tubes by recirculation pump.
High TDS and viscous liquid concentration

Application field:

High TDS Effluent Concentrate
Tomato Juice concentrate
Brine liquid concentration
Recovery of metal salts
Concentration of Pharma and textile effluent

Pre-sales Service:


Customization:
 We can specially customize products if you tell us any special requests,such as spare parts, cylindrical tank, material, output, pump...

After-sales Service:

 1. One-year free warranty and life-long maintenance service
 2. Equipment operation and maintenance vedio guide for the customers
 3. Help to do worker training
 4. On-line support every day

FAQ:

1.Q:Are you a factory or trading company?
  A:We are one of the largest evaporator manufactory in China
2.Q:Can we visit your factory before placing orders?
  A:Sure,warmly welcome to our factory!

3.Q:What's the info needed if I send  one inquiry?
 A:Pls tell us the working conditions,mediums,temperature,pressure,equipment's material,size,quantity,and other special requests

4.Q:What is the MOQ?
  A:We accept loose quantity order,any trial orders or mixed order

5.Q:How does your factory do quality control?

 A:Quality is priority,we make relevant strict testing before delivery
Our factory has already obtained ISO9001 quality and ISO 14001  Environmental  management system certificate
