- Size: as customer's request
- Place of Origin: Shandong
- Brand Name: shandong wintech machinery technology Co.,Ltd
- Model Number: WTPSA
- Weight: 200.000 kg
- :
- :
- :
- :
| Product sequence | PSA-(50-5500)/6Q |
| Nitrogen flow(Nm³/h) | 50-5500 |
| Nitrogen purity | 95%-99.999% |
| Rated pressure | ≤0.8 Mpa |
| Structure form | skid-mounted |
- Size: as customer's request
- Place of Origin: Shandong
- Brand Name: shandong wintech machinery technology Co.,Ltd
- Model Number: WTPSA
- Weight: 200.000 kg
- :
- :
- :
- :
the Principle of pressure swing adsorption of Nitrogen Generation:
The Pressure swing adsorption process for nitrogen uses carbon molecular sieve as adsorbent. Under a certain pressure, the carbon molecular sieve adsorption of oxygen in the air is far greater than that of nitrogen, the programmable control pneumatic valve opening and closing, A, B two towers can be alternately, pressurized adsorption and vacuum desorption, separation of oxygen and nitrogen, high purity nitrogen.
Application field: Inert gas and liquid storage above; blow washing of containers, pipes, reactor and the isolation room; synthetic fiber spinning, drawing anti chloride, anti-corrosion equipment, paint production in nitrogen, to prevent drying oils of polymerization; for the oil tanker provide protective gas (oil with nitrogen sealing and cleaning gas); marine engineering of inert gas supply; coke dry quenching, catalyst regeneration, oil fractionation, nitrogen fertilizer raw materials, catalyst protection, gas washing, rubber packing and storage, tire production; nitrogen pressure injection exploitation.
Pre-sales Service:
Customization:
We can specially customize products if you tell us any special requests,such as spare parts, cylindrical tank, material, output, pump...
After-sales Service:
1. One-year free warranty and life-long maintenance service
2. Equipment operation and maintenance vedio guide for the customers
3. Help to do worker training
4. On-line support every day
FAQ:
1.Q:Are you a factory or trading company?
A:We are one of the largest evaporator manufactory in China
2.Q:Can we visit your factory before placing orders?
A:Sure,warmly welcome to our factory!
3.Q:What's the info needed if I send one inquiry?
A:Pls tell us the working conditions,mediums,temperature,pressure,equipment's material,size,quantity,and other special requests
4.Q:What is the MOQ?
A:We accept loose quantity order,any trial orders or mixed order
5.Q:How does your factory do quality control?
A:Quality is priority,we make relevant strict testing before delivery
Our factory has already obtained ISO9001 quality and ISO 14001 Environmental management system certificate
